KRASO Spacer
KRASO Spacer
guarantees sufficient distance between the flexible empty pipes, light, impact resistant, weather and rot-proof plastic spacer
Appropriate accessories for KRASO Cable Penetration KDS and Cable Inlet Box KDS 150
Appropriate accessories for KRASO Cable Penetration KDS and Cable Inlet Box KDS 150
+ With the appropriate accessories KRASO Cable Penetration KDS 90 / KDS 150 and KRASO Cable Inlet Box System KDS 150 can be combined to a complete and individual system - as it is required for demanding construction projects.
+ Our experts are happy to assist you regarding the numerous possibilities - even on your construction site!
Info
Scope of supply:
KRASO Spacer 90, 110 or 150
KRASO Spacer 90, 110 or 150
Downloads
|
Type / Item |
KRASO Spacer 90 |
KRASO Spacer 110 |
KRASO Spacer 150 |
|
InternalDiameter ID in mm |
90 |
110 |
165 |
