KRASO Pump Sump Poly 400
KRASO Pump Sump Poly 400
for collecting waste water, with water pressure tight surrounding, thermally welded KRASO 4 Seal, shear key and pipe connection DN 110, suitable for KG, HT and KG 2000 pipes
| DafStB waterproof concrete guideline: stress class 1 + 2
Light and tight
+ Light and water pressure tight solution for sewage free of faeces - for new buildings or rehabilitation!
+ Saves time and money: simple installation due to light weight - no additional formwork or concreting sections for several days required!
+ Without higher risks occurring by leaky concreting joints and/or pipe connections!
+ DafStB waterproof concrete guideline: stress class 1 + 2
Info
Special sizes and designs available in request!
Downloads
KRASO Pumpensumpf Poly 400 - KG 2000
|
Type / Item |
KRASO Poly 400 / 60 |
KRASO Poly 400 / 80 |
|
|
Internal diameter in cm |
37 |
37 |
|
|
Internal height in cm |
60 |
80 |
|
|
DN 110 |
h1 |
20 |
20 |
|
DN 110 |
h2 |
41 |
|
|
Weight approx. in kg |
17 |
21 |
|
|
KRASO Pump Sump Poly 400 |
524 € |
614 € |
|
|
Surcharge: per each 10 cm additional height max. building element height 100 cm |
47 € |
||
|
Surcharge: for change of the height of the pipe connection |
23 € |
||
KRASO Pump Sump Type Q - square -
for collecting waste water suitable for KG, HT and KG 2000 pipes | DafStB waterproof concrete guideline: stress class 1 + 2Low weight - quick delivery: the simple and tight plastic solution+ Low weight = low transport costs and easy handling without crane on-site+ Saves time, labour, money and additional drainage: no cost-intensive works, no concreting sections for several days, no shuttering!+ No risk occuring due to leaking concrete joints and/or pipe connections+ Resistance against many acids and lyes!+ Made of high-quality, impact resistant, almost indestructible plastic. Special dimensions are available within a few days!
+ DafStB waterproof concrete guideline: stress class 1 + 2
KRASO Pump Sump Poly 400 - LR
for collecting waste water, with water pressure tight surrounding, thermally welded KRASO 4 Seal, shear key and pipe connection DN 110 suitable for KG, HT and KG 2000 pipes, water pressure tight empty pipe system with protective cover, pump sump protective cover for the shell construction phase | DafStB waterproof concrete guideline: stress class 1 + 2
Light and tight+ Light and water pressure tight solution for sewage free of faeces - for new buildings or rehabilitation!+ Saves time and money: simple installation due to light weight - no additional formwork or concreting sections for several days required!+ No higher risks occuring by leaking concreting joints and/or pipe connections! + DafStB waterproof concrete guideline: stress class 1 + 2
KRASO Pump Sump Poly 400 - complete
for collecting and pumping out of sewage free of faeces, with shear key and pipe connection DN 110 suitable for KG, HT and KG 2000 pipes, KRASO Poly 400 - Pump - (for sewage, excl. maintenance contract), empty pipe extension for the adjustment to subsequent floor construction | DafStB waterproof concrete guideline: stress class 1 + 2Light, tight, complete+ Light and water pressure tight complete solution for sewage free of faeces - for new buildings or rehabilitation!+ Saves time and money: simple installation due to light weight - no additional formwork or concreting sections for several days required!+ No higher risks occurring by leaking concrete joints and/or pipe connections! + DafStB waterproof concrete guideline: stress class 1 + 2
