KRASO Foil Clamping Flange Type FKF
for the sealing of media of all kinds of materials in front of a wall or in the core drilling, with foil flange 1,2 mm, according DIN 16937, oil- and bitumen resistant, surrounding approx. 15 cm, 30 mm seal | DIN 18533 W1 -E and W2.1 -E
The revolution in terms of the integration of media lines into the sealing of larger areas+ Innovative: water pressure tight sealing of any even and stable cable with our KRASO Foil Clamping Flange Type FKF foil flange!+ Suitable for all external diameters of media lines and for all materials!
+ We can individually customise the type of sealing sheets or foils: e.g. PVC, EPDM, FPO, RESITRIX®, PP, PE, KRASO-Fol, PYE-PV 200 S5 etc.
+ Torque Control Nut KRASO DKM: integrated torque limiter - no torque wrench required!+ Metal components made of non-corrosive stainless steel V2A.
+ For new buildings and rehabilitation! Various designs for almost every situation!
+ Simple and fast mounting!
+ MPA-tested: water pressure tight up to 2,5 bar!+ Tested according to FHRK testing specification GE 101!+ DIN 18533 W1 -E and W2.1 -E
KRASO Floor Penetration Type FBV-BDF
floor penetration for a conformist integration of FBV-films, made of high-quality, dimensionally and pressure stable solid wall material or KG 2000 (polypropylene (PP), mineral- filled, smooth walls, long-lasting, high impact strength), for installation in waterproof concrete base plates with fresh concrete composite film on the part of the building site, using the 20 cm sourrounding, angular FBV-sealing flange, Torque Control Nut KRASO DKM,
for connection to KG, HT or KG 2000 lines, approx. 50 cm long, with water pressure tight surrounding KRASO 4 Seal, formed plug-in sleeve on one side and KRASO Cover as installation aid | DafStB waterproof concrete guidline: Stress class 1 + 2
The effective sealing system
+ Floor Penetration for a conformist integration of fresh concrete composite films.
+ Vendor independence: fresh concrete composite films (FBV) of all vendors can be integrated.
+ KRASO FBV-Sealing Flange made of non-corrosive stainless steel V2A with angular fresh concrete composite film, surrounding 20 cm.
+ Torque Control Nut KRASO DKM: integrated torque limiter - no torque wrench required!
+ KRASO Floor Penetration Type BDF: the approved floor penetration with KRASO 4 Seal - MPA-tested up to 10 bar! Radon-tight!+ Made of dimensionally and pressure stable solid wall material with low abrasion! Easy installation at low temperatures.
+ Also available as KG 2000 made of polypropylene (PP), mineral- filled, smooth walls, long-lasting.
+ Formed plug-in sleeve on one side for the connection of KG, HT or KG 2000 - pipes.
+ Including KRASO Cover as an installation aid.
+ DafStB waterproof concrete guidline: Stress class 1 + 2
KRASO Wall Collar
for pressure-tight integration of pipelines with smooth surface (KG, KG 2000, HT) in waterproof concrete structures: Base plate and wall, MPA-tested up to 5 bar| DafStB waterproof concrete guideline: Stress class 1 + 2 + fast, simple and tight solution for sealing pipes in waterproof concrete constructions - base plate and wall
+ water-tight integration of pipelines: MPA-tested up to 5 bar! + Methane gas resistant! + for almost all smooth pipes in DN 110, DN 125 and DN 160: KG, KG 2000 and HT pipes + tool-free assembly - simple and fast:
the KRASO Wall Collar only has to be pulled over the pipe! The KRASO Wall Collar comes with a cover can be used during the construction period! + DafStB waterproof concrete guideline: Stress class 1 + 2
KRASO Floor Penetration Type BDF
in accordance with DIN EN 1401, for installation in waterproof base plates for connection to KG/ HT pipes, with water pressure tight surrounding KRASO 4 Seal, formed plug-in sleeve on one side and KRASO Cover as installation aid, also available with KRASO Foil Flange, oil- and bitumen resistant, surrounding approx. 15 cm. For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50 | DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-ESimple, tight and approved
+ The proven floor penetration with KRASO 4 Seal - MPA-tested up to 10 bar!
+ Radon-tight: prevents from a harmful to health concentration of the radioactive noble gas.+ Made of pressure- and dimensionally stable solid wall material with low abrasion! Easy installation at low temperatures.
+ Pipes and pipe material in accordance with terms of DIN EN 1401 (KG) or DIN EN 14758 (KG 2000).
+ Also available as KG 2000: made of polypropylene (PP), mineral- filled, smooth walls, long-lasting.
+ Also available with oil- and bitumen resistant KRASO Foil Flange.+ Formed plug-in sleeve on one side, for connection to KG/ HT pipes.
+ Including KRASO Cover as an installation aid.
+ KRASO Product Innovation: Type BDF as thermally insulated floor penetration!
+
DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E
KRASO Floor Penetration Type BDF - KG 2000
in accordance with DIN EN 14758, for the installation in waterproof base plates for connection to system KG 2000 lines, with water pressure tight surrounding, thermally welded KRASO 4 Seal, formed plug-in sleeve on one side and KRASO Cover as installation aid, also available with KRASO Foil Flange, oil- and bitumen resistant, surrounding approx. 15 cm. For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50 | DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E
Simple, tight and approved
+ The proven floor penetration with KRASO 4 Seal - MPA-tested up to 10 bar!
+ Radon-tight: prevents from a harmful to health concentration of the radioactive noble gas.+ Made of pressure- and dimensionally stable solid wall material with low abrasion! Easy installation at low temperatures.
+ Pipes and pipe material in accordance with terms of DIN EN 1401 (KG) or DIN EN 14758 (KG 2000).
+ Also available as KG 2000: made of polypropylene (PP), mineral- filled, smooth walls, long-lasting.
+ Also available with oil- and bitumen resistant KRASO Foil Flange.+ Formed plug-in sleeve on one side, for connection to KG/ HT pipes.
+ Including KRASO Cover as an installation aid.
+ KRASO Product Innovation: Type BDF as thermally insulated floor penetration!
+
DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E
KRASO Wall Collar
for pressure-tight integration of pipelines with smooth surface (KG, KG 2000, HT) in waterproof concrete structures: Base plate and wall, MPA-tested up to 5 bar| DafStB waterproof concrete guideline: Stress class 1 + 2 + fast, simple and tight solution for sealing pipes in waterproof concrete constructions - base plate and wall
+ water-tight integration of pipelines: MPA-tested up to 5 bar! + Methane gas resistant! + for almost all smooth pipes in DN 110, DN 125 and DN 160: KG, KG 2000 and HT pipes + tool-free assembly - simple and fast:
the KRASO Wall Collar only has to be pulled over the pipe! The KRASO Wall Collar comes with a cover can be used during the construction period! + DafStB waterproof concrete guideline: Stress class 1 + 2
Rodding eye for KRASO Type BDF
15 x 15 cm - screwable -Simple, tight and approved - KRASO Floor Penetration Type BDF+ The proven floor penetration with KRASO 4 Seal - MPA-tested up to 10 bar!
+ Radon-tight: prevents from a harmful to health concentration of the radioactive noble gas.+ Made of pressure- and dimensionally stable solid wall material with low abrasion! Easy installation at low temperatures.
+ Pipes and pipe material in accordance with terms of DIN EN 1401 (KG) or DIN EN 14758 (KG 2000).
+ Also available as KG 2000: made of polypropylene (PP), mineral- filled, smooth walls, long-lasting.
+ Also available with oil- and bitumen resistant KRASO Foil Flange.+ Formed plug-in sleeve on one side, for connection to KG/ HT pipes.
+ Including KRASO Cover as an installation aid.
+ KRASO Product Innovation: Type BDF as thermally insulated floor penetration!
+
DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E
KRASO Wall Collar
for pressure-tight integration of pipelines with smooth surface (KG, KG 2000, HT) in waterproof concrete structures: Base plate and wall, MPA-tested up to 5 bar| DafStB waterproof concrete guideline: Stress class 1 + 2 + fast, simple and tight solution for sealing pipes in waterproof concrete constructions - base plate and wall
+ water-tight integration of pipelines: MPA-tested up to 5 bar!+ IAF-tested: radon tight!+ Methane gas resistant! + for almost all smooth pipes in DN 110, DN 125 and DN 160: KG, KG 2000 and HT pipes + tool-free assembly - simple and fast:
the KRASO Wall Collar only has to be pulled over the pipe! The KRASO Wall Collar comes with a cover can be used during the construction period! + DafStB waterproof concrete guideline: Stress class 1 + 2
KRASO Wall Collar Lightning Protection Duo
for the waterproof integration of earthings with factory-closed openings| DafStB waterproof concrete guideline: Stress class 1 + 2+ for the waterproof integration of earthings with factory-closed openings: rectangular earthing tape (30 x 3,5 mm) and round earthing wire (ø 8 - 10 mm) + with Torque Control Wrench KRASO DKS: for safe and easy tightening of tension straps + MPA-tested up to 5 bar! + Methane gas resistant! + Radon tight – according to FHRK leaflet MB 101. + DafStB waterproof concrete guideline: Stress class 1 + 2
KRASO Flange Pipe Type KG
for retrofit installation, for connection to KG/HT lines, made of high-quality, dimensionally and pressure stable solid wall material, with formed plug-in sleeve on one side and KRASO Foil Flange, oil- and bitumen resistant, surrounding approx. 15 cm. For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50. | DIN 18533 W1-E and W2.1-ESimple and effective integration into bituminous sealing
+ For new building and rehabilitation - according DIN 18533 W1-E and W2.1-E.
+ Simple and effective integration into bituminous sealing (“black tank“): bitumen thick coating (e.g. KMB) and sheeting, concrete and brick wall.
+ Water pressure tight up to 1,5 bar - MPA-tested!
+ Made of dimensionally and pressure stable solid wall material with low abrasion! Easy to install at low temperatures.+ Pipe and pipe material in accordance with DIN EN 1401 (KG) or DIN EN 14758 (KG 2000).
KRASO Flange Pipe Type KG 2000
for retrofit installation, for the connection to KG 2000 lines, made of high-quality, dimensionally and pressure stable solid wall material, with formed plug-in sleeve on one side and KRASO Foil Flange, oil- and bitumen resistant, surrounding approx. 15 cm. For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50. | DIN 18533 W1-E and W2.1-E
Simple and effective integration into bituminous sealing+ For new building and rehabilitation - according DIN 18533 W1-E and W2.1-E.+ Simple and effective integration into bituminous sealing (“black tank“): bitumen thick coating (e.g. KMB) and sheeting, concrete and brick wall.+ Water pressure tight up to 1,5 bar - MPA-tested!+ Made of dimensionally and pressure stable solid wall material with low abrasion! Easy to install at low temperatures.+ Pipe and pipe material in accordance with DIN EN 1401 (KG) or DIN EN 14758 (KG 2000).
Legend
![](https://www.kraso.de/bundles/krasotheme/icons/Label_Druckwassergeprueft_10bar_Vierstegdichtung_EN.png?16969909248249)
Regarding our wall and pipe penetrations the KRASO 4 Seal reliably keeps pressurised water out: The material testing institute certifies a water pressure tightness up to 10 bar! Due to its construction the KRASO 4 Seal is securely fixed to the concrete. It is joined to the solid wall pipe monolithically (force-fit) in a special process. This completely prevents any creep or slippage.
![](https://www.kraso.de/bundles/krasotheme/icons/Label_Druckwassergeprueft_10bar_EN.png?16969909248994)
Whether KRASO Pump Sumps made of concrete, Flange Plates, Tie Points or Sealing Inserts: they all offer reliable protection against pressing water due to their construction, material and processing. All these products have been tested by independent material testing institutes regarding their water pressure tightness and are proof against pressurised water up to 10 bar!
![](https://www.kraso.de/bundles/krasotheme/icons/Label_gas-undgeruchsdicht-n_EN.png?16969909248398)
Not only against pressing water — KRASO Sealing Inserts are additionally gas- and odour-tight and therefore high-quality in terms of TA-Air! Due to a successful proof in a material testing institute our sealing inserts include the administrative regulation of the Federal Immission Control Act: “Technical Instructions on Air Quality Control TA-Air”.
![](https://www.kraso.de/bundles/krasotheme/icons/dkm_EN.png?169699092410013)
Products with Torque Control Nut KRASO DKM can be installed without having to use a torque wrench. The correct torque moment is integrated in the KRASO DKM. The installation has never been so easy and installation errors can be avoided.
![](https://www.kraso.de/bundles/krasotheme/icons/radon-dicht_EN.png?16969909246975)
Radon (Rn) is a radio-active noble gas which develops in rock earth. Via ground air this colour- and odourless gas can enter basement rooms through leakages. Radon is the second most common cause for lung cancer. Pipe penetrations with KRASO 4 Seal and KRASO Sealing Inserts are gas tight and therefore reliably protect your building against the intrusion of radon.
![](https://www.kraso.de/bundles/krasotheme/icons/Label_DVGW_EN.png?16969909247959)
The DVGW — The German Technical and Scientific Association for Gas and Water - certified that KRASO Sealing Inserts are gas-tight according to DIN EN13611 (sector 7.2). Our sealing inserts therefore meet the criteria for the German Association for Gas and Water.
![](https://www.kraso.de/bundles/krasotheme/icons/Label_DVGW-cert.png?169699092412295)
The KRASO Builder's Convenience Box has the application from DVGW - German Technical and Scientific Association for Gas and Water - according DVGW VP 601 as house connection for gas and water and therefore fulfils all directives for a gas- and water pressure tight installation.
![](https://www.kraso.de/bundles/krasotheme/icons/Label_brandsicher_F180_EN.png?16969909248080)
The so-called “fire-resistance grading” gives information about the DIN normed fire resistance of building materials. The grading shows the letter ”F” along with the time span of the functional integrity in minutes. With 180 minutes of functional integrity the fire-resistance grading F 180 therefore stands for a highly- fire-resistant material.
![](https://www.kraso.de/bundles/krasotheme/icons/Label_ABP.png?16969909248684)
Test certificates from recognised material testing institutes verify the usability of KRASO Joint Tapes, as e.g. KRASO Duo-Fix 150 “plus”, according the guidelines of the German Institute for Structural Engineering. The test certificate proofs the usability according state building regulations.
![](https://www.kraso.de/bundles/krasotheme/icons/FHRK-Quality.png?16969909246048)
KRASO Products with a "FHRK Quality" – icon meet the testing specifications of FHRK e.V. - the trade association for house connections for pipes and cables. The tests cover all possible stresses on sealing inserts, house connection systems, pipe penetrations and casings: for example, gas- and water pressure tightness, abrasion resistance when backfilling formwork or resistance when compacting the building pit.
![](https://www.kraso.de/bundles/krasotheme/icons/FHRK-Radondicht.png?16969909248358)
KRASO Products with the icon "FHRK Radondicht" have been tested according FHRK or/and DVGW testing specifications regarding their gas- and water pressure tightness and have also been successfully tested for diffusion resistance by the IAF. Products with this seal are radon-tight!
