KRASO Plastic Flange Plate Type KFP - split -
for installation of pipes or cables using a sealing insert (not included in the scope of supply), ID = InternalDiameter | DafStB waterproof concrete guideline: stress class 1 + 2, with foil flange DIN 18533 W1 -E and W2.1 -E
A proven solution reinvented
+ Like a "split casing": the flange plate made of high-strength plastic can be installed retrospectively
+ No core drilling: no need for the separation of media lines for installation!
+ Installation in front of a wall made of waterproof concrete or as KRASO Type KFP with foil flange in front of a wall with sealing of larger areas
+ Easy installation by just one person thanks to the low weight!
+ Latest CNC production technology: absolute dimensional compliance - no tolerances like they are usual with solutions involving metal
+ Tongue and groove system: the two halves of the plastic flange plate pull together with 100% accurate fit automatically. Installation errors are thus avoided due to this innovation!
+ Subsequent sealing of the media lines in the plastic flange plate using a sealing insert
+ DafStB waterproof concrete guideline: stress class 1 + 2, with foil flange DIN 18533 W1 -E and W2.1 -E
Info
Scope of supply:
KRASO Plastic Flange Plate Type KFP - split - or KRASO Plastic Flange Plate Type KFP - Foil Flange - split -, EPDM flat seal to the component and fixing material, adhesive and sealant KRASO PU 50
KRASO Plastic Flange Plate Type KFP - split - or KRASO Plastic Flange Plate Type KFP - Foil Flange - split -, EPDM flat seal to the component and fixing material, adhesive and sealant KRASO PU 50
Further sizes and diameters available on request!
Downloads
KRASO Kunststoffflanschplatte Typ KFP - geteilt -
|
Type / Item |
KRASO Type KFP - split - • KRASO Type KFP - Foil Flange- split |
||||||
|
InternalDiameter ID |
80 |
100 |
125 |
150 |
200 |
250 |
300 |
|
max. external diameter pipe or cable |
0 - 55 |
0 - 75 |
0 - 100 |
0 - 125 |
0 - 175 |
0 - 225 |
0 - 275 |
|
Plate size approx. in mm |
d = 240 |
d = 260 |
d = 285 |
d = 310 |
d = 360 |
d = 410 |
d = 460 |
|
KRASO Plastic Flange Plate Type KFP |
363 € |
374 € |
403 € |
422 € |
488 € |
556 € |
613 € |
|
KRASO Plastic Flange Plate Type KFP |
454 € |
469 € |
505 € |
527 € |
611 € |
696 € |
765 € |
slide 1 to 2 of 2
KRASO PU 50
high-quality, permanently elastic and strong PU-sealant, also usable on moist surfaces, recommended for all products with KRASO Foil Flange, colour black, 290 ml cartridge for cartridge press
KRASO KFP Installation Kit
suitable for KRASO Plastic Flange Plate Type KFP: KRASO Torque Wrench, socket wrench insert 8, Ø 19 mm nut, cartridge pressing pistol. blower for drilled holes
