KRASO Floor Drain - thermally insulated -

Inside and outside - tight and dry

+ For interior areas, for basements, yards and parking levels: KRASO Drains for a reliable and water pressure tight drainage of water! Radon-tight!

+ Walkable and fit for traffic, frost proof and odour tight, backwater safe and thermally insulated: manifold versions for different needs!

+ High-quality components for a secure installation and use: solid wall material with thermally welded KRASO 4 Seal, plastic- or stainless steel grates.

+ Additional accessories as completion for individual needs.

+ DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E

Info

Scope of supply:

KRASO Floor Drain - thermally insulated -, screwable stainless steel grate class K3, with odour stopper and sludge trap filter, building period protective cover

Downloads

Produktinformation

Produktinfo_KRASO_Bodendurchfuehrung_Typ_BDF_waermegedaemmt (969.38 KiB)

Datenblatt

Datenblatt_KRASO_Bodenablauf_KG2000_wärmegedämmt (182.69 KiB)

Prüfzeugnis

Prüfbericht_KRASO_Vierstegdichtung_TPE (310.25 KiB)
Prüfbericht_KRASO_Vierstegdichtung (606.1 KiB)

DWG-Dateien

DWG_KRASO_Bodenablauf_wärmegedämmt_- (4.23 MiB)

Type / Item	KRASO Floor Drain - thermally insulated -
Drainage capacity	1,79 l/s
Height	drain approx. 110 mm
Insert frame	from 30 - 70 mm can be rotated and is fully height-adjustable
Stainless steel grate	class K3 (withstands loads of up to 300 kg), 15 x 15 cm
Connection	either KG/HT pipes or KG 2000 - pipes DN 50 or DN 110 vertical

Downloads auf ausschreiben.de

KRASO Floor Drains - Accessories

accessories for KRASO Floor Drains+ Insert frame extension height > 140 mm + Insert frame extension with foil flange height > 140 mm, foil flange (d = approx. 50 cm)+ Insert frame extension - fit for traffic up to 1,5 t can be rotated and is height-adjustable from 15 - 120 mm, all visible parts are made of stainless steel, stable stainless steel grate massive, screwed, 150 x 150 mm, fit for traffic up to 1,5 t, L 15+ Insert frame all visible parts are made of stainless steel incl. stainless steel grate+ Stainless steel grate class K3+ Stainless steel grate - screwable - incl. insert frame with threaded sleeves+ Raising element for thin-bed mortar screed structure height from 25 - 130 mm+ Spare parts kit consisting of: backflow seal, odour stopper, sludge trap filter, insert frame and plastic grate+ Floor Drain insert frame with building period protective cover suitable for industry floors

KRASO Floor Drain

according DIN EN 1253 - for the installation in interior areas without traffic, for the drainage of grey water, drainage capacity: 1,79 l/s, with water pressure tight surrounding KRASO 4 Seal. Also available with KRASO Foil Flange, oil- and bitumen resistant (d = approx. 50 cm). For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50. | DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E Inside and outside - tight and dry + For interior areas, for basements, yards and parking levels: KRASO Drains for a reliable and water pressure tight drainage of water! Radon-tight! + Walkable and fit for traffic, frost proof and odour tight, backwater safe and thermally insulated: manifold versions for different needs! + High-quality components for a secure installation and use: solid wall material with thermally welded KRASO 4 Seal, plastic- or stainless steel grates. + Additional accessories as completion for individual needs.+ DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E

KRASO Floor Drain - KG 2000

according DIN EN 1253 - for the installation in interior areas without traffic, for the drainage of grey water, drainage capacity: 1,79 l/s, with water pressure tight surrounding, thermally welded KRASO 4 Seal. Also available with KRASO Foil Flange, oil- and bitumen resistant (d = approx. 50 cm). For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50. | DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E Inside and outside - tight and dry + For interior areas, for basements, yards and parking levels: KRASO Drains for a reliable and water pressure tight drainage of water! Radon-tight! + Walkable and fit for traffic, frost proof and odour tight, backwater safe and thermally insulated: manifold versions for different needs! + High-quality components for a secure installation and use: solid wall material with thermally welded KRASO 4 Seal, plastic- or stainless steel grates.+ Additional accessories as completion for individual needs.+ DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E

KRASO Floor Drain Type FS - RS - frost proof - backwater safe

for the installation in outdoor areas without traffic, for the drainage of grey water, drainage capacity: 0,4 l/s, with water pressure tight surrounding, thermally welded KRASO 4 Seal. Also available with KRASO Foil Flange, oil- and bitumen resistant (d = approx. 50 cm). For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50. | DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E Frost proof - backwater safe + For installation in outdoor areas without traffic, for the drainage of grey water, drainage capacity:0,4 l/s.+ All year use due to its frost proof backwater double stopper. + KG 2000: high impact strength and persistence. + Screwable stainless steel grate: class K3 up to max. 300 kg.+ DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E

KRASO Floor Drain Type FS - frost proof

for the installation in outdoor areas without traffic, for the drainage of grey water, drainage capacity: 1,67 l/s, with water pressure tight surrounding KRASO 4 Seal. Also available with KRASO Foil Flange, oil- and bitumen resistant (d = approx. 50 cm). For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50. | DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E Inside and outside - tight and dry + For interior areas, for basements, yards and parking levels: KRASO Drains for a reliable and water pressure tight drainage of water! Radon-tight! + Walkable and fit for traffic, frost proof and odour tight, backwater safe and thermally insulated: manifold versions for different needs! + High-quality components for a secure installation and use: solid wall material with thermally welded KRASO 4 Seal, plastic- or stainless steel grates.+ Additional accessories as completion for individual needs.+ DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E

KRASO Floor Drain Type FS - KG 2000 - frost proof

for the installation in outdoor areas without traffic, for the drainage of grey water, drainage capacity: 1,67 l/s, with water pressure tight surrounding, thermally welded KRASO 4 Seal. Also available with KRASO Foil Flange, oil- and bitumen resistant (d = approx. 50 cm). For the integration of the foil flange we recommend our adhesive and sealant KRASO PU 50. | DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E Inside and outside - tight and dry + For interior areas, for basements, yards and parking levels: KRASO Drains for a reliable and water pressure tight drainage of water! Radon-tight! + Walkable and fit for traffic, frost proof and odour tight, backwater safe and thermally insulated: manifold versions for different needs! + High-quality components for a secure installation and use: solid wall material with thermally welded KRASO 4 Seal, plastic- or stainless steel grates.+ Additional accessories as completion for individual needs.+ DafStB waterproof concrete guidline: Stress class 1 + 2, with foil flange DIN 18533 W1-E
